A270 Biopharm (Bpe) Tubing Stainless Steel Seamless Pipe 304 Stainless Steel Seamless Pipe

Brand Name : Gnee

Model Number : 201 304 316l

Certification : SGS

Place of Origin : TISCO

MOQ : 1 Tons

Price : 1,250.00 $

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 Tons per Month

Packaging Details : seaworthy export packing with fumigated wooden pallets or steel pallets

Material : Stainless Steel 201 304 316l

Outer Diameter : 6-630mm or customized

Thickness : 0.4-30mm or customized

Standard : JIS, AiSi, ASTM, GB, DIN, EN

Processing Service : Bending, Welding, Decoiling, Punching, Cutting, Moulding

Type : Round Pipe Tube

Surface : 2B/NO.4/HL/NO.1/BA

Length : 1000-6000mm or Customer's Requirement

Grade : 300 Series,400 Series,200 Series,201/202/304 /304L/316/316L321/310s/410/420/430/440/439ect

Tolerance : ±1%

Technique : Cold Rolled Hot Rolled

Application : Construcion/Building /Industry

Contact Now

A270 Biopharm (Bpe) Tubing Stainless Steel Seamless Pipe 304 Stainless Steel Seamless Pipe

A270 BioPharm (BPE) Tubing

* Bright Annealed Polished Stainless Steel BPE Tubing
* Available in 20Ra SF1 & 15Ra SF4 ElectroPolished Finish
* 3A Certified for sanitary line process requirements
* This product ships via freight carriers. Polished Bio-Pharmaceutical (BPE) stainless steel tubing is manufactured in accordance with ASTM A270. Our tubing is made from cold-rolled stainless steel strip whose chemical elements are specially controlled to enhance weldability. The weld bead is cold-worked to a full finished condition, resulting in a virtually undetectable longitudinal weld. Bright annealing follows in a controlled atmosphere to preserve maximum structural integrity. Read more about ASTM Standards. Material Test Reports (MTRs) available upon request.

A270 BioPharm (BPE) Tubing Part Numbers & Dimensions
Size (Tube OD)
Part Number
Dimensions
304
316L
Wall Thickness
ID
Gauge
1/2"
A270P-304050
A270P-316050
0.065
0.370
16
3/4"
A270P-304075
A270P-316075
0.065
0.620
16
1"
A270P-304100
A270P-316100
0.065
0.870
16
1-1/2"
A270P-304150
A270P-316150
0.065
1.37
16
2
A270P-304200
A270P-316200
0.065
1.87
16
2-1/2"
A270P-304250
A270P-316250
0.065
2.37
16
3
A270P-304300
A270P-316300
0.065
2.87
16
4
A270P-304400
A270P-316400
0.083
3.834
14

Number of Tube Sticks Per Case
Size (Tube OD)
Piece Count
Total Footage
1"
15
300"
1-1/2"
15
300"
2"
15
300"
2-1/2"
15
300"
3"
10
200"
4"
5
100"

Additional Tube Specifications
Size (Tube OD)
Dimensions
Weight per Foot (lbs)
Burst Pressure (PSI)
Wall Thickness
Gauge
1/2"
0.065
16
0.30
10,833
3/4"
0.065
16
0.48
8,666
1"
0.065
16
0.66
9,750
1-1/2"
0.065
16
1.00
6,503
2"
0.065
16
1.35
4,875
2-1/2"
0.065
16
1.70
3,900
3"
0.065
16
2.05
3,248
4"
0.083
14
3.50
2,730
6"
0.109
14
5.29
1,820

Tube Tolerances
Part Number
O.D.
Wall
OD Tolerance
Wall Tolerance
Ovality Tolerance
Box Qty.
ASTM Standards
00507
0.5
0.065
+.002/-.008
+/-.008
*
300
A213/A270
00757
0.75
0.065
+.002/-.008
+/-.008
*
300
A213/A270
01007
1
0.065
+.002/-.008
+/-.008
*
300
A249/A269/A270
01507
1.5
0.065
+.002/-.008
+/-.008
*
300
A249/A269/A270
02007
2
0.065
+.002/-.011
+/-.008
*
300
A249/A269/A270
02507
2.5
0.065
+.002/-.011
+/-.008
*
300
A249/A269/A270
03007
3
0.065
+.003/-.012
+/-.008
*
200
A249/A269/A270
04007
4
0.083
+.003/-.015
+/-.010
*
100
A249/A269/A270
06007
6
0.109
+.030/-.030
+/-.010
*
20
A249/A269/A270
A270 Biopharm (Bpe) Tubing Stainless Steel Seamless Pipe 304 Stainless Steel Seamless PipeA270 Biopharm (Bpe) Tubing Stainless Steel Seamless Pipe 304 Stainless Steel Seamless Pipe
FAQ
Q: Could you provide OEM service?
A: Yes, OEM service is available. You can contact us by e-mail, tel, skype, etc.
Q: Is it possible to develop new design type at special requirement?
A: Yes, we have professional R&D team for any special requirement on the product. We offer ODM service for customers.
Q:How much does 1 stick of 4" tube weigh?
A: One 20' Stick of 4" Sanitary Tubing weighs approximately 75 pounds.
Q:You list gauge of this tubing at 16, but the wall thickness at 0.065". Isn't 16 gauge 0.0625"?
A: The wall thickness and gauges are all displayed in the table below. Please contact us if you have any other questions.
